Configure Parameters

• CPU

  RK3399, dual Cortex-A72 large core + four Cortex-A53

• GPU

  Quad-core ARM Mali-T860MP4 high-performance GPU

• RAM

  Standard 2G

• ROM

  Standard 16G

• System

  Android 7. 1+

Panel Parameters

• Panel Size

  86 inches

• Liquid Crystal Type

  LCD

• Backlit Form

  Direct style

• Resolution

  2D：3 8 4 0 × 2 1 6 0 3D：1280X720

• Maximum Brightness

  450nit

• Contrast

  3000:1

• Viewing Angle

  Up, down, left and right: 89°/89°/89°/89°

• Refresh Rate

  60Hz

• Response time

  8ms

• Chroma

  1.07B

3D Display Technology

• Optical Lenses

  3D lenses

• Binocular Tracking

  unnecessary

• 3D Out Of the Screen

  65cm

• 3D display of field of view

  60 degrees

• 3D shows the optimal range

  200cm-1000cm

• operating system

  Supports Windows/Android dual systems

Functional Applications

• WIFI

  Set WIFI, support dual-band WIFI, single antenna

• Network Standard

  Ethernet x 1

• Playback Mode

  Loop playback mode is supported

• Video Format

  MP4、AVI、MKV

• Video Input

  HDMI

• Audio Format

  MP3、WMA、AAC

• Speaker

  Two-channel 2*10w

• USB port

  USB3. 0*2 /USB2. 0*2 / RJ45*1

• Touch interface

  USB-B*1 (rear side)/USB-B*1 (front), not valid at the same time

Operating Environment/Power Supply

• Service Life

  5000hr

• Operating Temperature

  0℃～ 40℃

• Operating Humidity

  20~80% RH (no condensation）

• Storage Temperature

  -5℃～ 45℃

• Store Humidity

  20~ 90% RH (no condensation)

• Voltage

  100~ 240VAC（50～ 60Hz）

• power Consumption

  Max 235W

Installation and packaging

• Appearance size (bare metal)

  1644*1050*240mm

• Net Weight

  70kg

• Gross Weight

  85kg

• Installation

  Wall-mounted, mobile bracket (optional)
